Dormakaba Transom Door Closer EN3 Non Hold Open Body Only
85311101

Transom Closer allows a single or double action aluminium door or doors to be closed with precision.

Transom Closer Function - Above the door, a concealed in the aluminium transom profile ensures that the door closes after usage.

  • For single and double action doors RH (ISO 5) and LH (ISO 6)
  • Offers a solution for installations where door control must be provided without disturbing the aesthetic appearance of the door.
  • Certified to ISO 9001.

Features:

  • For single and double action doors
  • Backcheck function as standard
  • Wide range of accessories for almost every configuration
  • Concealed in the door frame

Specifications:

  • Length: 323mm
  • Width: 90mm
  • Height: 38mm
  • Weight: 4.7kg
  • Max Door Width: 950mm
  • Max Door Weight: 110kg
  • Max Opening Angle: 130 degrees
  • Closing Force: EN3
  • Internal Doors Max: 950mm
  • Closing Speed Variable Valve Adjustment: Yes
  • Final Closing Speed Variable Valve Adjustment: Yes
  • Backcheck: Yes
  • Protection:
    • Certified manufactur to ISO 9001.
    • Certification CE marked.
    • Successful independently tested to BS EN 1154
SKU DORM85311101
Barcode # 6949536240365
Brand Dormakaba
